INVT Goodrive300-19 Series Operation Manual page 38

Goodrive300-19 series open loop vector inverter special for hosit
No. Name
2 Unit LED
Code
3
displaying
zone
TRIP
Mean the unit displayed currently
5-figure LED display displays various monitoring data and alarm code such as
set frequency and output frequency.
Description
operation and remote communication
control
LED off means that the inverter is in the
keypad operation state; LED blinking
means the inverter is in the terminals
operation state; LED on means the
inverter is in the remote communication
control state.
LED for faults
LED on when the inverter is in the fault
state; LED off in normal state; LED
blinking means the inverter is in the
pre-alarm state.
Hz
RPM
A
%
V
-37-
Keypad operation procedure
Frequency unit
Rotating speed unit
Current unit
Percentage
Voltage unit
