Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
Hierarchical
multi-step
P19.06
speed
reference 0
Hierarchical
multi-step
P19.07
speed
reference 1
Hierarchical
multi-step
P19.08
speed
reference 2
Hierarchical
multi-step
P19.09
speed
reference 3
Hierarchical
multi-step
P19.10
speed
reference 4
Hierarchical
multi-step
P19.11
speed
reference 5
FWD
P19.12 switching-off
frequency
P19.13 FWD
Detailed instruction of parameters
switching-off and switching-on signals.
Hierarchical multi-step speed reference is specially
designed according to the application modes of hoists
(hierarchical joystick/hierarchical remote control).
Goodrive300-19 inverters can set 6 steps speed,
which can be selected by the combination of
hierarchical reference terminals 1~5 (set by S
terminal function, the corresponding function codes
are P05.01~P05.09), corresponding to the speed 0 to
speed 5.
The relations between terminal 1, terminal 2, terminal
3, terminal 4, terminal 5 and hierarchical multi-step
speed are:
Hierarchical
reference terminal 1
Hierarchical
reference terminal 2
Hierarchical
reference terminal 3
Hierarchical
reference terminal 4
Hierarchical
reference terminal 5
Hierarchical
multi-step speed
Note: Only when all lower hierarchical references
close can the upper hierarchical references close.
Generally, set hierarchical multi-step speed
reference 0 to 0.0% when using hierarchical
terminal reference.
Setting range: 0.0~100.0%
The three parameters are switching-off conditions in
forward rotation. The inverter will send switching-off
signal after the
switching-off frequency
OFF ON ON ON ON ON
OFF OFF ON ON ON ON
OFF OFF OFF ON ON ON
OFF OFF OFF OFF ON ON
OFF OFF OFF OFF OFF ON
0 1 2 3
running frequency
and torque
-113-
Function parameters
Default
value
0.0%
0.0%
0.0%
0.0%
0.0%
4 5
0.0%
2.00Hz
exceeds
verification
0.0%
Modify
○
○
○
○
○
○
◎
◎
