Figure 29: Overview Image
The Drive Assembly is comprised of two parts: the storage drive and the drive carrier. The carrier
attaches to the exterior of the data storage drive and caddies the drive into the enclosure. It stabilizes
the motion of the drive into the drive bay so that the drive properly mounts onto the drive board.
3.8.1 Drive Assembly Specifications
Specification
Number per Enclosure
Part Number
Hot Swappable?
Weight
3.8.2 Drive Assembly Layout
up to 102 drives
See the List of Compatible Drives
find the specific part number required.
Yes
.68 kg / 1.5 lbs.
51
3. Component Overviews
3.8 Drive Assembly Description
Value
(page 17) to
