User Guide
Figure 79: Unlatching a CMA Connector
7. Install the CMA.
a.
Note: The CMA arms are connected to the rails and the enclosure's chassis by
two connectors with the elbow on the left side.
Orient the CMA so that the elbow is on the left hand side.
b. Attach the connectors to the brackets on the rails and chassis. There should be one at
the elbow side and two at the other end.
Figure 80: CMA Orientation
102
4. Part Replacement
4.8 CMA Lite Replacement
