User Guide
IOM Fan
Rails (CMA Standard)
Rails (CMA Lite)
CMA Standard
CMA Lite Kit (w/ rails, spacer brackets, and CMA)
CMA Lite Arm
CMA Lite Tray
CMA Cable Tray
3.5 in. Drive Carrier, Qty=1
3.5 in. to 2.5 in. conversion Drive Carrier, Qty=1
3.5 in. Drive Blank, Qty=1
Power Cable for PDU, C13-C14, 18AWG, 3m, Qty=1
HD Mini-SAS to HD Mini-SAS, 3m, Qty=2
1.7 LEDs
1.7.1 Front and Rear IO LEDs
The Ultrastar Data102 has a number of LEDs on the exterior of the enclosure that display various
system statuses. There are three on the front and three on the rear that mirror each other and
provide general status. This allows the status of the enclosure to be visible from either side of the
rack.
Component
8
1. Overview
Part Number
1EX0432
1EX0435
1EX1601
1EX0437
1EX1825
1EX1834
1EX1603
1EX1119
1EX0438
1EX0439
1EX0429
1EX1158
1EX1533
