User Guide
designator type: NAA,
transport: Serial Attached SCSI Protocol (SPL-4)
0x5000ccab0300003c
designator type: Relative target port,
transport: Serial Attached SCSI Protocol (SPL-4)
Relative target port: 0x1
Target device that contains addressed lu:
designator type: NAA,
transport: Serial Attached SCSI Protocol (SPL-4)
0x5000ccab0300003c
4. Build the sg_senddiag command using the information recorded in earlier steps.
a. Use the example of the sg_senddiag command shown in the image above to complete
the specific sg_senddiag command for IOM A. Replace letters a through d with the
information recorded in previous steps.
sg_senddiag Command
sg_senddiag <a> --pf --raw=04,00,00,90,<b>,<c>,00,00,<d>
a. sg device (<dev>): device associated with IOM A
b. Disable Zoning: 60
c. Zoning Configuration: configuration 00
Note: For information on preconfigured zoning configurations, see:
Predefined Zoning Configurations
d. IOM SAS Address: SAS Address associated with IOM A
Note: A comma should be placed after each bit of data in the IOM SAS
Address that was recorded. For example, if the IOM SAS Address output
was 5000CCAB0300003C, the address that should be added to the
sg_senddiag command should be 50,00,CC,AB,03,00,00,3C.
b. Use the example of the sg_senddiag command shown in the image above to complete
the specific sg_senddiag command for IOM B. Replace letters a through d with the
information recorded in previous steps.
sg_senddiag Command
sg_senddiag <a> --pf --raw=04,00,00,90,<b>,<c>,00,00,<d>
a. sg device (<dev>): device associated with IOM B
b. Disable Zoning: 60
c. Zoning Configuration: configuration 00
code set: Binary
code set: Binary
code set: Binary
(page 227).
241
5. System Management
5.3 Zoning
