User Guide
Figure 212: Two Host Configuration Example
Note: The diagram displays red SAS cables to indicate passive connections between the
host and the enclosure. The black SAS cables indicate active connections between each
enclosure.
• Two SAS Enclosures: Two Host with a Single HBA
• Two SAS Enclosures: Two Host with Two HBAs
• Three SAS Enclosures: Two Host with a Single HBA
• Three SAS Enclosures: Two Host with Two HBAs
• Four SAS Enclosures: Two Host with a Single HBA
• Four SAS Enclosures: Two Host with Two HBAs
• Four SAS Enclosures: Two Hosts Non-Redundant
5.5.2 One Host Cable Configurations
This section provides the information required to connect two or more enclosures to a single host
via SAS connections. Choose the cable map that fits the preferred daisy chaining requirement.
261
5. System Management
5.5 Daisy Chaining
