User Guide
Figure 84: Cover Retention Screws
12. Now that the chassis is installed, test the installation by sliding the enclosure in and out of the
rack a minimum of three times. If the enclosure binds, catches, or displays any incorrect motion
or behavior retry the installation.
Note: Adjustments of the vertical rack rails may be required to fix any issues that may
occur.
13. Grasp both handles at the front of the enclosure and pull with even pressure to extend the
chassis out of the rack until it is stopped by the safety latches. The safety latches will prevent
the enclosure from coming out of the rack completely and the cover will remain in the rack
attached to the rear alignment brackets.
106
4. Part Replacement
4.8 CMA Lite Replacement
