User Guide
The IOM Blank is a placeholder component that is used to fill the unused IOM slot. in versions of
the Ultrastar Data102 that do not leverage redundant IOMs. The IOM Blank may only be installed
into IOM slot B under all circumstances. When at the front of the enclosure, Slot B is the left-hand
slot. It is necessary to have a blank installed in this unused slot in order to ensure the proper airflow
dynamics that are within operational parameters designed for the enclosure, but has no functional
component beyond this feature.
3.3 PSU Description
Figure 17: Overview Image
Ultrastar Data102 contains redundant 1600W Power Supply Units (PSU). Each PSU requires an
input voltage of between 200 - 240 VAC. The PSUs are 80 PLUS Platinum certified, and utilize C14
power cable receptacles.
3.3.1 PSU Specifications
Power Output
80 PLUS Standard
Specification
1600W
Platinum
37
3. Component Overviews

3.3 PSU Description

Value
