HGST Ultrastar Data102 User Manual page 275

User Guide
Table 43: Two Enclosures: One Host with Two HBAs
Hardware
Host Connections
Enclosure Connections
Table 44: Three Enclosures: One Host with Two HBAs
Hardware
Host Connections
Enclosure Connections
Source Device
Host1: P1
Host1: P2
Host1: P3
Host1: P4
Enclosure1: IOMA, A3
Enclosure1: IOMA, A4
Enclosure1: IOMB, B3
Enclosure1: IOMB, B4
Source Device
Host1: P1
Host1: P2
Host1: P3
Host1: P4
Enclosure1: IOMA, A3
Enclosure1: IOMA, A4
Enclosure1: IOMB, B3
Enclosure1: IOMB, B4
Enclosure2: IOMA, A3
Enclosure2: IOMA, A4
Enclosure2: IOMB, B3
Enclosure2: IOMB, B4
265
5. System Management
5.5 Daisy Chaining
Destination Device
Enclosure1: IOMA, A1
Enclosure2: IOMB, B3
Enclosure1: IOMB, B1
Enclosure2: IOMA, A3
Enclosure2: IOMA, A1
Enclosure2: IOMA, A2
Enclosure2: IOMB, B1
Enclosure2: IOMB, B2
Destination Device
Enclosure1: IOMA, A1
Enclosure3: IOMB, B3
Enclosure1: IOMB, B1
Enclosure3: IOMA, A3
Enclosure2: IOMA, A1
Enclosure2: IOMA, A2
Enclosure3: IOMB, B1
Enclosure3: IOMB, B2
Enclosure3: IOMA, A1
Enclosure3: IOMA, A2
Enclosure3: IOMB, B1
Enclosure3: IOMB, B2
