User Guide
10 Site and System Operation Requirements
10.1 Power Requirements
The following table describes the A/C input power specification for the Ultrastar Data102.
Table 54: AC Power Specifications
Alternating Current (AC) Power Supply (2 per enclosure)
Wattage (per power supply)
Note: Max and typical power consumption
values represent the output power to the
system. Input power will vary depending
on the PSU efficiency and load sharing
between PSUs
Voltage (per power supply)
Maximum inrush current (per power supply)
Caution: The Ultrastar Data102 can only be plugged into high line (220-240 VAC). If the unit
is plugged into low line (110-127 VAC), the PSU will report a "Critical" state when status pages
are queried using SES. In this case, the enclosure will power up, but the drives will not. The
enclosure will remain in low-power mode.
10.2 Supported Operating Systems
Table 55: Compatible Operating Systems
Microsoft® Windows Server 2012 R2 x64
Microsoft® Windows Server 2016 R1 x64
RedHat® Red Hat Enterprise Linux (x86_64) 7.4
RedHat® Red Hat Enterprise Linux (x86_64) 7.3
10. Site and System Operation Requirements
Power
Supply Rating: 80 PLUS Platinum rated
Max Power Consumption: ~1600W
Typical Power Consumption: ~1300W
200 - 240 VAC, auto-ranging, 50/60 Hz
AC line inrush current shall not exceed 40A
peak, for up to one-quarter of the AC cycle after
which, the input current should be no more than
the specified maximum input current.
Operating System
10
10.1 Power Requirements
