5. System Management
5.5 Daisy Chaining
User Guide
Figure 214: Enclosure Configurations with One Host with Two HBAs
Note: The diagram displays red SAS cables to indicate passive connections between the
host and the enclosure. The black SAS cables indicate active connections between each
enclosure.
264
