User Guide
• <IOM B Gateway> = The gateway, in four pairs of two-digit hex codes
The result, after setting the two static addresses in
Configuration
e3,01,00,30,03,00,00,00,00,00,00,00,C0,A8,00,0A,FF,FF,FF,00,C0,A8,00,01,
00,00,00,00,C0,A8,00,0A,FF,FF,FF,00,C0,A8,00,01 <dev>
The result, when IOM B is not booting (no IP):
e3,01,00,30,03,00,00,00,00,00,00,00,C0,A8,00,0A,FF,FF,FF,00,C0,A8,00,01,
00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00 <dev>
Note: Setting an invalid gateway will result in that field being zeroed-out.
5.3 Zoning
5.3.1 Before Zoning
This section provides information on actions that should be taken before starting zoning on the
Ultrastar Data102.
Users should install all of the required downloads before beginning the zoning process.
Required Downloads:
• SMP Tools 0.98 for Linux:
• SG3 Utils:
http://sg.danny.cz/sg/sg3_utils.html
• CLI Tools: to download the latest version of CLI tools, see:
Support Portal
5.3.2 Predefined Zoning Configurations
There are three predefined zoning configurations for the Ultrastar Data102. Each configuration
allows the user connect a different number of hosts that have access to a set number of drives.
Each of these drives are part of a grouping called a zone group. This section displays the
necessary information related to each of the predefined zoning configurations.
Configuration 0:
(page 225):
http://sg.danny.cz/sg/smp_utils.html
(page 205)
Changing the OOBM Network
Downloading Firmware from the
227
5. System Management
5.3 Zoning
