The following is an image of the layout of the major system components inside the Ultrastar Data102.
Figure 4: Component Layout
1.6 List of Customer Replaceable Units (CRUs)
The following table lists the replaceable components and their part numbers.
Table 6: List of Replaceable Components
Ultrastar Data102 Chassis with a single IOM and PSU
Ultrastar Data102 Chassis with IOMs and PSUs
IOM
IOM Blank
PSU 1600W
Rear Fan
Chassis Cover
Rear Cover Alignment Brackets
Rails
Component
1.6 List of Customer Replaceable Units (CRUs)
Component
1EX0440
1EX0441
1EX0430
1EX0431
1EX0434
1EX0433
7
1. Overview
Part Number
