sg_wr_mode /dev/sg3 --dbd --page=0x23,0x01 --
contents=e3,01,00,1A,01,00,00,00,01,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00
• Device = /dev/sg3
• IOM = 01 (IOM A)
• Setting = 01 (DHCP)
• IP Address = 0.0.0.0
• Netmask = 0.0.0.0
• Gateway = 0.0.0.0
To change the OOBM network configuration on IOM B to DHCP:
sg_wr_mode /dev/sg3 --dbd --page=0x23,0x01 --
contents=e3,01,00,1A,02,00,00,00,01,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00
• Device = /dev/sg3
• IOM = 02 (IOM B)
• Setting = 01 (DHCP)
• IP Address = 0.0.0.0
• Netmask = 0.0.0.0
• Gateway = 0.0.0.0
Viewing the OOBM Network Configuration
1. To view the OOBM network configuration, enter the following:
sg_wr_mode <dev> --dbd --page=0x23,0x01
This returns:
e3,01,00,30,03,00,00,00,<IOM A Setting>,00,00,00,<IOM A IPaddr>,<IOM
A Netmask>,<IOM A Gateway>,00,00,00,<IOM B Setting>,00,00,00,<IOM B
IPaddr>,<IOM B Netmask>,<IOM B Gateway>
• <IOM> = 03 (IOMA & IOMB)
• <IOM A Setting> = 00 (static) or 01 (DHCP)
• <IOM A IPaddr> = The IP address in four pairs of two-digit hex codes
• <IOM A Netmask> = The netmask, in four pairs of two-digit hex codes
• <IOM A Gateway> = The gateway, in four pairs of two-digit hex codes
• <IOM B Setting> = 00 (static) or 01 (DHCP)
• <IOM B IPaddr> = The IP address in four pairs of two-digit hex codes
• <IOM B Netmask> = The netmask, in four pairs of two-digit hex codes
5.2 Configuring OOBM Network Settings
