4. Part Replacement
4.10 Chassis Replacement
User Guide
Figure 163: Unlatching IOM Handles
c. Align the IOM with the empty slot on the top of the chassis so that the arrow on the IOM
latch release is facing toward the side shown in the following image.
d. Slowly lower the IOM into the empty slot while being careful to keep it level. Do not to
force it.
180
