HGST Ultrastar Data102 User Manual page 131

User Guide
14. Remove the chassis from the rack.
a. Be prepared to support the enclosure once it is free of the rails by having a second
person or a lift to support the enclosure
b. Grasp both handles at the front of the enclosure and pull with even pressure until the
enclosure will not extend further.
c. Locate the safety catches on the inner rails attached to the enclosure.
Warning: The handles on the front of the chassis are not
intended to be used to support the weight of the Ultrastar Data102.
Lifting the unit by the chassis handles or trying to support the unit on the
handles can cause them to fail. This can cause serious damage to the
unit or serious bodily harm to those handling the unit. Always team lift
the chassis by gripping the underside of the unit, and never try to lift a
chassis that is filled with drives.
121
4. Part Replacement
4.9 Rails Replacement
