4. Part Replacement
4.10 Chassis Replacement
User Guide
Figure 171: Cinching Cable Retention Clip
41. Install the second PSU.
42. Install Rear Fan
a. Orient the rear fan as shown in the following image.
b. Insert the rear fan into the housing as shown in the following image.
187
