User Guide
Table 2: Electrical Specifications
Specification
Max Power Consumption
Typical Power Consumption
Note: Max and typical power consumption
values represent the output power to the
system. Input power will vary depending
on the PSU efficiency and load sharing
between PSUs
Input Voltage
PSU Connector Type
Inrush Current Maximum (per PSU)
PSU Efficiency
Caution: The Ultrastar Data102 can only be plugged into highline. If the unit is plugged into
lowline, the PSU will report a "Critical" state when status pages are queried using SES. In this
case, the enclosure will power up, but the drives will not. The enclosure will remain in low-
power mode.
Table 3: Mechanical Specifications
Specification
Shock
Vibration
Weight
Dimensions with CMA
Length without CMA
Required Rack Width
1.4 Ultrastar Data102 Specification Summary
~1600W
~1300W
200 - 240 VAC
C14
AC line inrush current shall not exceed 40A
peak, for up to one-quarter of the AC cycle after
which, the input current should be no more than
the specified maximum input current.
80 PLUS Platinum
Non-Operational
10G, 0 - peak,11ms half sine; 3
positive and 3 negative pulses
in each axis Shock
0.75G, 0 - peak swept sine; 5
-500Hz; 1 complete sweep @
1/2 octave per minute
118.8 kg / 262 lbs.
W: 447mm x L: 1197 mm x H: 175mm / W: 17.6in. x L: 47.13in. x
H: 6.89in.
1026 mm / 40.39in.
450mm with (17.72in.) with 465mm (18.31in.) ± 1.5mm nominal
hole spacing. See EIA-310 Rack Standard
4
1. Overview
Value
Operational
5G, 0 - peak, 11ms half sine;
3 positive and 3 negative
pulses in each axis- minimum
6 seconds between shocks to
allow for write/read recovery
0.10G,0 - peak swept sine; 5
-500Hz; 1 complete sweep @
1/2octave per minute
