4. Part Replacement
4.9 Rails Replacement
User Guide
Figure 95: Chassis Handle Operation
9. Follow these steps to remove a Drive Assembly.
a. Find the latch release mechanism on the Drive Assembly being removed.
b. Insert a finger and a thumb into the latch release and pinch to unlatch the Drive
Assembly.
117
