User Guide
5
3.4 Rear Fan Description
Figure 19: Overview Image
The Rear Fans are toolless fan modules that provide the primary system cooling for the Ultrastar
Data102. They are attached to the rear of the chassis in the fan housing by a 6 pin connector and
two latches, that also provides power and control signals to the modules.
3.4.1 Rear Fan Specifications
Table 21: Specification Summary
Number per Enclosure
Part Number
Hot Swappable?
FRU or CRU?
Weight
Number
Specification
Handle
4
1EX0433
Yes
CRU
318 g / .7 lbs
40
3. Component Overviews
3.4 Rear Fan Description
Feature
Value
