3. Component Overviews

3.8 Drive Assembly Description

User Guide
Number Feature
5 Elbow Connector
3.7.3 CMA Cable Tray
Figure 28: Overview Image
The cable management assembly (CMA) comes with an optional CMA tray that is used to support
cable loads greater then ten (five per arm). This tray is mounted at the bottom of the chassis using
four M3 x 8mm T10 Torx screws (two per side). Use this cable tray in cases where cables might
interfere with the lower U space beneath the chassis.
3.8 Drive Assembly Description
50
