User Guide
Number
6
7
The chassis has a removable lid that encloses the internal system components and ensures proper
airflow. The drive bays are comprised of 16 sections that isolate the data storage drives from
transmitting vibration to one another. There is a long central bay that contains the enclosure's IOMs
and the IOM fan. The front of the chassis has a metal mesh cover and two handles that swing out
from the chassis that are used to extend the enclosure out of the rack when pulled. There are two
rack ears at the front of the enclosure that are used to secure the enclosure to the rack for shipping
purposes. The rear of the chassis has two housings to shroud and connect the four rear fans to the
enclosure, and a center bay that houses the PSU modules.
Warning:
support the weight of the Ultrastar Data102. Lifting the unit by the chassis handles or trying to
support the unit on the handles can cause them to fail. This can cause serious damage to the
unit or serious bodily harm to those handling the unit. Always team lift the chassis by gripping
the underside of the unit, and never try to lift a chassis that is filled with drives.
3.2 IOM Description
IOM A Dual HD-Mini SAS Ports (x6)
1GB Ethernet Port (x1)
IOM B Dual HD-Mini SAS Ports (x6)
1GB Ethernet Port (x1)
The handles on the front of the chassis are not intended to be used to
Feature
32
3. Component Overviews

3.2 IOM Description
