User Guide
• Raise and lower the cooling fans.
• Enable or disable activity safeguards which limit enclosure activity to reduce power consumption
or heat generation.
• Enter a self-healing thermal offline state in which some or all enclosure components are
powered off.
• Power off the enclosure (not self-healing).
The enclosure operates visual indicators. These indicators can be set or cleared via host request,
or autonomously by the enclosure if it detects fault conditions. The enclosure provides non-volatile
memory that records enclosure serialization and branding information. The SEP records event log
entries to non-volatile memory. The SEP implements T10 defined SMP controlled "zoning on the
fly", and has the capability to save the host defined zoning parameters in non-volatile memory. The
SEP also implements several predefined zoning configurations. These predefined configurations are
selectable via SES control operations.
2.2 OOBM Management Overview
The Ultrastar Data102 uses an implementation of DMTF Redfish for out-of-band system
management. All the SES enclosure information can be obtained through the out-of-band
management port using RESTful API calls to the management port over HTTPS.
2.3 SCSI Enclosure Services Page 02
The SCSI
Send Diagnostic
a specific SES element in the enclosure. There are many different element codes, such as Page 02,
defined to cover a wide range of devices. Page 02 refers to the control and status of the enclosures
PSUs, HDDs, ESMs, and sensors.
Note: Refer to the SES Firmware Management Interface Specification for more information on
SES Page 02.
and
Receive Diagnostic Results
28
2. System Management Overview

2.2 OOBM Management Overview

commands can be addressed to
