b. Issue the following command to access a single host's SMP Discover output:
smp_discover_list /dev/bsg/expander-9:39
c. Zone group 9 can be identified by the
The above example displays PHYs 0-13 as being in zone group 9. All other devices
are labeled as
access to. The step can be repeated on other hosts to see what zone group each host
has access to.
d. Issue the following command to access all hosts smp_discover_list:
smp_discover_list --ignore /dev/bsg/expander-9:39
e. Zone group 9, 10, 11, 12, 13, and 14 can be identified by the
each group in each of their respective zones. The above example displays PHYs 0-13
as being in zone group 9, PHYs 14-27 as being in zone group 10, and so on.
5.3.7 Disabling Zoning using Windows
PENDING - Remove references to sg and replace with SCSI device handles.
1. From the host server, identify the SCSI devices that are associated with the Ultrastar Data102
IOMs.
Note: The operating system associates each SEP device as a SCSI device. The
SCSI device of the SEP can be used to get status from or control elements within the
enclosure.
a. Issue the following command:
sg_scan -s | findstr /i H4102-J
b. Identify the SCSI devices from the output. The device information follows SCSI0. The
devices appear as SCSI0:1,62,0 and SCSI0:1,124,0 bolded in the example below.
SCSI0:1,62,0
0101
0428
SCSI0:1,124,0
0101
0428
2. Locate the IP Address for each IOM using sg_ses page 7.
a. Issue the following command:
sg_ses <dev> -p7 | finstr /i esce
ZG:9
because the host is displaying the only devices it has
inaccessible
claimed=0 pdt=dh
claimed=0 pdt=dh
247
5. System Management
located at the end of each line in zone 9.
located at the end of
ZG
