HGST Ultrastar Data102 User Manual page 181

User Guide
Figure 154: Slide Inner Rail
d. Caution:
use the special Low-Profile M4 x 3.2mm Philips screws provided in the accessory
kit with the CMA. These screws should be tightened to .90-1.12 Nm / 8-10 in-
lbf using a # 2 Philips Screwdriver. These screws are specially designed for this
purpose. Using unapproved screws could cause damage to the slides inside the
rail.
Install the three special low-profile M4 x 3.2mm Philips screws provided to secure the
inner rail to the chassis.
When installing the inner rail onto the chassis, make sure to only
171
4. Part Replacement
4.10 Chassis Replacement
Click
Click
