User Guide
sg_senddiag Command
sg_senddiag <a> --pf --raw=04,00,00,90,<b>,<c>,00,00,<d>
a. sg device (<dev>): device associated with IOM B
b. Enable Zoning: 61
c. Zoning Configuration: configuration 01, 02, or 03
Note: For information on preconfigured zoning configurations, see:
Predefined Zoning Configurations
d. IOM SAS Address: SAS Address associated with IOM B
Note: A comma should be placed after each bit of data in the IOM SAS
Address that was recorded. For example, if the IOM SAS Address output
was 5000CCAB0300007C, the address that should be added to the
sg_senddiag command should be 50,00,CC,AB,03,00,00,7C.
c. The following are examples of completed sg_senddiag commands for IOM A and B.
• IOM A: sg_senddiag /dev/sg3 --pf --
raw=04,00,00,90,61,01,00,00,50,00,CC,AB,03,00,00,3C
• IOM B: sg_senddiag /dev/sg106 --pf --
raw=04,00,00,90,61,01,00,00,50,00,CC,AB,03,00,00,7C
5. Enable zoning on IOM A using the sg_senddiag command.
a. Issue the command for IOM A that was built in the previous step.
b. Enabling a predefined zoning configuration will reset the SAS connector ports which
may cause the sg_senddiag command to return a status of DID_TIME_OUT or
DID_SOFT_ERROR. Despite the error, the zoning configuration will be enabled. The
zoning configuration can be verified after both IOMs have been zoned.
send diagnostic: transport: Host_status=0x03 [DID_TIME_OUT]
Driver_status=0x00 [DRIVER_OK]
6. Enable zoning on IOM B using the sg_senddiag command.
a. Issue the command for IOM B that was built in the previous step.
b. Enabling a predefined zoning configuration will reset the SAS connector ports which
may cause the sg_senddiag command to return a status of DID_TIME_OUT or
DID_SOFT_ERROR. Despite the error, the zoning configuration will be enabled. The
zoning configuration can be verified after both IOMs have been zoned.
send diagnostic: transport: Host_status=0x03 [DID_TIME_OUT]
Driver_status=0x00 [DRIVER_OK]
(page 227).
238
5. System Management
5.3 Zoning
