4. Part Replacement
4.10 Chassis Replacement
User Guide
Figure 182: Connected Cable Routing
d. Wrap cable tie around the installed cable bundle between the ports and the first basket
of the CMA
Note: Each cable must be given enough slack at the connector end to operate
smoothly. For the upper CMA allow 20" - 21" (508 – 533.4mm) between the
end of the connector and the first basket. Make sure to route all of the upper
CMA cables under the lower CMA cables.
