5. System Management
5.5 Daisy Chaining
User Guide
Figure 216: Enclosure Configurations with Two Hosts with a Single HBA
Note: The diagram displays red SAS cables to indicate passive connections between the
host and the enclosure. The black SAS cables indicate active connections between each
enclosure.
268
