User Guide
Figure 94: Unlatching a CMA Connector
7. Complete the previous step for the second CMA.
Warning:
The following steps regarding uninstalling drives from the enclosure should
be followed in order to reduce the weight enough to remove the chassis during the rails
replacement process. However, if there is proper lift/support equipment rated to support the full
weight of the enclosure, 118.8 kg / 262 lbs. , these steps can be skipped. If not, please follow
these drive removal instructions to remove all of the drives and reduce the weight. Never try to
support the weight of the full system by hand. Doing so could cause damage to the system
or serious bodily harm.
8. Grasp both handles at the front of the enclosure and pull with even pressure to extend the
chassis out of the rack until it is stopped by the safety latches. The safety latches will prevent
the enclosure from coming out of the rack completely and the cover will remain in the rack
attached to the rear alignment brackets.
116
4. Part Replacement
4.9 Rails Replacement
