Figure 13: Layout
5
4
5
6
Table 18: Exterior Components
Number
1 IOM and IOM Fan Bay
2 Drive Bay
3 Chassis Handles
4 Rear Fans Bays
5 PSU Bays
4
7
31
3. Component Overviews
3.1 Chassis Description
1
2
3
Feature
3
