HGST Ultrastar Data102 User Manual page 297

User Guide
d. Pinch the latch release and carefully press downward to seat the Drive
Assembly the rest of the way.
5. Push the enclosure back into the rack to ensure proper cooling.
Cause
Something else.
Solution
1. Unseat the enclosure.
a. Remove the shipping screws.
b. Pull the enclosure out of the rack.
2. Remove the drive from the drive bay.
3. Inspect both the drive and drive carrier.
4. Install the drive.
Figure 229: Installing a Drive Assembly
287
6. Drives missing in the system management
5.5 Daisy Chaining
