User Guide
Configuration 1 allows up to six redundantly configured hosts to view a specific zone group
of drives. Each host will be able to view up to 17 drives that are mapped to both IOMs. Each
zone group will display all of the devices that are contained within that zone. If a drive slot is not
populated, it will still be part of that zone group, but it will not display any results in enclosure
management until the drive slot has been populated. In this Configuration, the enclosure is divided
into six zone groups as shown in the image below represented by six different colors. Each zone
group matches to a single SAS port on each side of the rear IOM to allow for the connections to six
different hosts.
• In-band management: Configuration 1 can be initiated in the sg_senddiag command in-band
by using 01 in the Zoning Configuration option. See:
the actual senddiag commands.
• Out-of-band management: Configuration 1 can be initiated in the out-of-band management
by using 1 in the ZoningConfig option. The following are example Redfish POST and cURL
commands:
Redfish POST:
/redfish/v1/Systems/Self/Storage/<Enclosure Logical ID>/Actions/
Storage.Zoning
{ "ZoningConfig": "1" }
cURL:
curl -X POST -k -u admin:admin -H "Content-type: application/json"
https://<IP Address>/redfish/v1/Systems/Self/Storage/<Enclosure Logical
ID>/Actions/Storage.Zoning -d
'{"ZoningConfig" : "1"}'
sg_senddiag Command
229
5. System Management
5.3 Zoning
(page 234) for
