HGST Ultrastar Data102 User Manual page 233

User Guide
1. Open a web browser, go to: https://portal.wdc.com/Support/s/, and download the firmware
package for the Ultrastar Data102.
2. Extract the downloaded zip file and place file in a location that is accessible to the Ultrastar
Data102.
3. Make a POST call to the UpdateService object using the
POST /redfish/v1/UpdateService/Actions/UpdateService.SimpleUpdate
HTTP/1.1
Content-Type: application/json;charset=utf-8
Content-Length: <computed length>
OData-Version: 4.0
Authorization: Basic userid:password
a. In the body of the POST, list the
this parameter to the file location of the bin file.
Note: TFTP and HTTPS are supported.
Linux Example:
{"ImageURI": "tftp://<tftp IP
Server60-8_SEP_bundle_2033-001_2.2.15.tar.gz"}
Windows Example:
{\"ImageURI\":\"https://<https IP
Server60-8_SEP_bundle_2033-001_2.2.15.tar.gz\"}
4. To check the status of this process, make a GET request to the following target:
Note: This command may need to be issued multiple times until it reports a
completed status. This should be done before completing the remainder of the
procedure.
curl -G -k -u admin:admin -H "Content-type: application/
json" https://<IP address>/redfish/v1/UpdateService/Actions/
UpdateService.SimpleUpdate/Status
a. Execute the command until you see the following result:
{
"ErrorCode":0,
"StatusCode":2,
"Description":"FW update completed. Waiting for activation.",
"EstimatedRemainingMinutes":0
}
ImageURI
address>/HGST_Ultrastar-DATA60-DATA102-
address>/HGST_Ultrastar-DATA60-DATA102-
223
5. System Management
SimpleUpdate
as the data parameter, and set the value of
5.1 Firmware Upgrade
action.
