Figure 211: One Host Configuration Example
Note: The diagram displays red SAS cables to indicate passive connections between the
host and the enclosure. The black SAS cables indicate active connections between each
enclosure.
• Two SAS Enclosures: One Host with a Single HBA
• Two SAS Enclosures: One Host with Two HBAs
• Three SAS Enclosures: One Host with a Single HBA
• Three SAS Enclosures: One Host with Two HBAs
• Four SAS Enclosures: One Host with a Single HBA
• Four SAS Enclosures: One Host with Two HBAs
• Four SATA Enclosures: One Host with a Single HBA
Two Host Configurations: The following diagram is an example of how the enclosures will be
connected via the IO SAS ports and what number each enclosure is. This information can be
utilized with this cable map:
Two Host Cable Configurations
