User Guide
b. Enable Zoning: 61
c. Zoning Configuration: configuration 01, 02, or 03
Note: For information on preconfigured zoning configurations, see:
Predefined Zoning Configurations
d. IOM SAS Address: SAS Address associated with IOM A
Note: A comma should be placed after each bit of data in the IOM SAS
Address that was recorded. For example, if the IOM SAS Address output
was 5000CCAB0300003C, the address that should be added to the
sg_senddiag command should be 50,00,CC,AB,03,00,00,3C.
b. Use the example of the sg_senddiag command shown in the image above to complete
the specific sg_senddiag command for IOM B. Replace letters a through d with the
information recorded in previous steps.
sg_senddiag Command
sg_senddiag <a> --pf --raw=04,00,00,90,<b>,<c>,00,00,<d>
a. SCSI device (<dev>): device associated with IOM B
b. Enable Zoning: 61
c. Zoning Configuration: configuration 01, 02, or 03
Note: For information on preconfigured zoning configurations, see:
Predefined Zoning Configurations
d. IOM SAS Address: SAS Address associated with IOM B
Note: A comma should be placed after each bit of data in the IOM SAS
Address that was recorded. For example, if the IOM SAS Address output
was 5000CCAB0300007C, the address that should be added to the
sg_senddiag command should be 50,00,CC,AB,03,00,00,7C.
c. The following are examples of completed sg_senddiag commands for IOM A and B.
• IOM A: sg_senddiag 3 --pf --
raw=04,00,00,90,61,01,00,00,50,00,CC,AB,03,00,00,3C
• IOM B: sg_senddiag 106 --pf --
raw=04,00,00,90,61,01,00,00,50,00,CC,AB,03,00,00,7C
5. Enable zoning on IOM A using the sg_senddiag command.
a. Issue the command for IOM A that was built in the previous step.
(page 227).
(page 227).
245
5. System Management
5.3 Zoning
