Actual value parameters from diameter calculation

Actual value parameter
No. Identifier
Actual Value Diameter Dact
841
Speed Factor
842
Torque Factor
843
Gear Factor Linefreq. to Winderfreq.
844
at Dmin
5.3

Electronic gear (speed setpoint)

The implemented electronic gear is used for scaling any frequency source with factors and adding an
offset if necessary. In this way, a line speed can be considered as a pilot value for the winding pro-
cess, or winding at a fixed line speed can be achieved, taking the diameter calculator into account.
The output of the electronic gear is wired to the input of the reference value ramp.
The frequency ramps (Parameters 420 - 425) must be set steep enough so that the
winding drive can follow the changing line speed.
5.3.1

Parameter

Activating the electronic gear
The electronic gear is activated via Parameter
TRUE, the output frequency is calculated and the gear stage is evaluated. Otherwise, the reference
value of the reference frequency channel is used.
Parameter
No. Identifier
Activate el. Gear
830
Reference frequency source
The source of the reference frequency to be scaled is selected in Parameter
point
831.
Parameter
No. Identifier
Source Frequency Setpoint
831
32
T
