Prevent ESD Damage

Related Information
"Safety Information" on page 62
■
"Tools Needed for Service" on page 63
■
"Component Service Task Reference" on page 65
■
"Removing Power From the Server" on page 67
■
Prevent ESD Damage
Many components housed within the chassis can be damaged by electrostatic discharge. To
protect these components from damage, perform these steps before opening the chassis for
service. See
Prepare an antistatic surface to set parts on during the removal, installation, or
1.
replacement process.
Place ESD-sensitive components such as the printed circuit boards on an antistatic mat.
2. Attach an antistatic wrist strap.
When servicing or removing server components, attach an antistatic strap to your wrist and then
to a metal area on the chassis.
Related Information
"Disconnect Power Cords and Data Cables" on page 70
■
"Removing the Server From the Rack" on page 72
■
"Remove the Top Cover" on page 77
■
"Safety Information" on page 62
■

Removing the Server From the Rack

Before you can remove the top cover to access components inside of the server chassis,
you might have to remove the server from the rack. Two rackmounting configurations are
supported:
"Remove the Server From the 4-Post, 19-inch Rack" on page 73
■
"Remove the Server From the 2-Post, 19-inch Rack" on page 74
■
Related Information
"Disconnect Power Cords and Data Cables" on page 70
■
72 Netra Server X5-2 Service Manual • October 2016
"Safety Information" on page 62.
