Install a CPU
Note -
distribute the compound.
12. Carefully align the heat sink screws to the mounting posts.
The "System Front" label must face the front of the server.
Caution -
lead to CPU damage.
Tighten the four captive screws of the CPU heat sink.
13.
Alternate between the screws in an X pattern, turning each one-half revolution, until they are
fully seated.
14. Review this information and complete these postrequisites in this order.
"Install the Air Duct" on page 249
■
208 Netra Server X5-2 Service Manual • October 2016
Do not distribute the compound. The spring pressure of the heat sink will evenly
Moving the heat sink too much unevenly distributes the thermal compound and can
