Remove a CPU

No.
2
3
4
5
Remove a CPU
Removing a CPU is a cold-service operation. You must power off the server before you remove
the CPU.
1. Determine which CPU to remove.
See "Locate a Faulty CPU" on page
Consider your next step.
2.
If you have not prepared for service, do so now. See
■
If you are removing a CPU as part of another component's removal or installation
■
procedure, go to
3. Review this information and complete these prerequisites in this order.
"Rotate the Drive Cage to the Service Position" on page 82
■
"Remove the Air Duct" on page 83
■
4. Locate the CPU to remove.
See "CPU Configuration" on page
Loosen the four captive screws of the CPU heat sink.
5.
198 Netra Server X5-2 Service Manual • October 2016
Description
Release button
CPU pin 1 alignment
Securing clip (one on each side)
CPU (upside down, a triangle indicates pin 1)
196.
Step 3.
195.
"Preparing for Service" on page 61.
