Oracle netra X5-2 Service Manual page 19

No. Description
1, 2 Power supplies (PS1 and PS0) (Note: AC supply
shown)
3 The number of available PCIe3 slots depends on
the CPU configuration.
■ Single Processor – PCIe3 slots 5 and 6 on
right
■ Dual Processor – PCIe3 slots 1, 2, 3, and 4 on
left and PCIe3 slots 5 and 6 on right
4 Video port (HD-15)
5 NET MGT RJ-45 network port for SP
6 USB 3.0 ports
7 SER MGT RJ-45 serial port for SP
8 Network 100/1000/10000 ports (NET0 to NET3)
for host
9 Grounding studs
10 Chassis Status LEDs
■ Locator LED and button
■ Service Required LED
■ Main Power OK LED
Related Information
"Component Locations (Storage, Power, and Fan Modules)" on page 14
■
"Component Locations (Motherboard, Memory, and PCIe Cards)" on page 16
■
"Front Panel Components (Service)" on page 17
■
"Rear Panel LEDs" on page 33
■
Rear Panel Components (Service)
Links
"Servicing Power Supplies" on page 119
"Servicing PCIe Cards" on page 137
"Video Port" in Netra Server X5-2 Installation Guide
"Access the SP (Oracle ILOM)" on page 28
"USB Ports" in Netra Server X5-2 Installation Guide
"Access the SP (Oracle ILOM)" on page 28
"10 Gigabit Ethernet Ports" in Netra Server X5-2
Installation Guide
"Connect the Chassis Ground Wire" in Netra Server
X5-2 Installation Guide
"Rear Panel LEDs" on page 33
Identifying Components 19
