Install the USB Flash Drive

Install the USB Flash Drive
Installing the USB flash drive is a cold-service operation. You must power off the server before
installing the USB flash drive.
1. Consider your first step.
If you are replacing the USB flash drive, remove the faulty or obsolete USB flash drive first,
■
then return to this procedure,
If you are installing the USB flash drive as part of another component's removal or
■
installation procedure, go to
If you are installing a new USB flash drive, go to
■
Position the USB flash drive to where it installs onto the motherboard.
2.
The USB flash drive installs into the USB socket that is near the middle of the motherboard.
The socket is labeled USB 0. See
Cards)" on page
3. Gently insert the USB flash drive into the USB socket.
4. Consider your next step.
If you installed the USB flash drive as part of a replacement operation, go to
■
152 Netra Server X5-2 Service Manual • October 2016
Step 2. See
Step 2.
"Component Locations (Motherboard, Memory, and PCIe
16.
"Remove the USB Flash Drive" on page
Step 2.
150.
Step 5.
