No. Name
2 Drives
3 Chassis
4 LED board
5 Drive backplane data cable
6 Drive SAS cables
7 Top cover
8 DVD SATA cable
9 Drive backplane power cable
10 Fan modules
11 Fan tray
12 USB board
13 Power supplies
14 DVD drive
Related Information
"Component Locations (Motherboard, Memory, and PCIe Cards)" on page 16
■
"Front Panel Components (Service)" on page 17
■
"Rear Panel Components (Service)" on page 18
■
"Component Service Task Reference" on page 65
■
Component Locations (Storage, Power, and Fan Modules)
Service Links
"Servicing SAS Drives" on page 93
"Accessing Internal Components" on page 71
"Servicing the LED Board" on page 211
"Servicing the System Cables" on page 155
"Servicing the System Cables" on page 155
"Remove the Top Cover" on page 77
"Install the Top Cover" on page 257
"Servicing the System Cables" on page 155
"Servicing the System Cables" on page 155
"Servicing Fan Modules" on page 129
"Remove the Fan Tray" on page 80
"Install the Fan Tray" on page 255
"Servicing the USB Board" on page 219
"Servicing Power Supplies" on page 119
"Servicing the DVD Drive" on page 113
Identifying Components 15
