Install the DVD SATA Cable

"Returning the Server to Operation" on page 247
■
Install the DVD SATA Cable
Installing a cable is a cold-service operation. You must power off the server before installing the
cable.
1. Consider your first step.
If you are replacing a DVD SATA cable, remove the faulty or obsolete cable first, then
■
return to this procedure,
See
If you are installing a cable as part of another component's removal or installation
■
procedure, go to
2. Connect the DVD SATA cable to the motherboard connector.
3. Route the DVD SATA cable to the drive backplane.
4. Review this information, and complete these prerequisites in this order.
"Install the Fan Tray" on page 255
■
166 Netra Server X5-2 Service Manual • October 2016
Step
"Remove the DVD SATA Cable" on page
Step 2.
2.
164.
