Netra Server X5-2 Service Manual • October - Oracle netra X5-2 Service Manual

Remove the Server From the 2-Post, 19-inch Rack
3. For both types of kits, remove the two screws securing each hardmount bracket
at the front of the rack.
4. For the sliding rail kit, extend the server to the locked position, and then, press
the Release buttons on the rails to pull the server out of the rack.
5. Lift the server from the rack and set it aside on an antistatic mat.
6. Remove the top cover.
See "Remove the Top Cover" on page
Related Information
"Prevent ESD Damage" on page 72
■
"Remove the Top Cover" on page 77
■
"Install the Top Cover" on page 257
■
"Safety Information" on page 62
■
Remove the Server From the 2-Post, 19-inch Rack
Support the weight of the server for removal.
1.
74 Netra Server X5-2 Service Manual • October 2016
77.
