3.
Disconnect all remaining cables from the motherboard and move them out of the
way.
Remove the four bus bar screws.
4.
Fully loosen the two captive screws at the front of the motherboard.
5.
Grasp the two motherboard handles and slide the motherboard forward off of the
6.
alignment pins.
Remove the Motherboard
Servicing the Motherboard
231
