3. Route the SAS drive signal cable cable to the drive backplane.
Review this information, and complete these prerequisites in this order.
4.
"Install the Fan Tray" on page 255
■
"Install a Fan Module" on page 133
■
Install all fan modules.
5. Connect the SAS drive signal cable to the drive backplane connector.
See "System Cable Configuration" on page
6. Consider your next step.
If you installed the cable as part of a replacement operation, go to
■
If you installed the cable as part of another component's removal or installation procedure,
■
return to that procedure.
See "Component Service Task Reference" on page 65
7. Finish the installation procedure.
See "Returning the Server to Operation" on page
Related Information
"Remove the SAS Drive Signal Cable" on page 157
■
"Component Locations (Storage, Power, and Fan Modules)" on page 14
■
"Preparing for Service" on page 61
■
"Returning the Server to Operation" on page 247
■

Remove the Backplane Data Cable

Removing a cable is a cold-service operation. You must power off the server before you remove
the cable.
1. Determine location of the backplane data cable.
See "System Cable Configuration" on page
2. Consider your next step.
If you have not prepared for service, do so now.
■
See "Preparing for Service" on page
If you are removing a cable as part of another component's removal or installation
■
procedure, go to
156.
156.
61.
Step 3.
Remove the Backplane Data Cable
Step
for assistance.
247.
Servicing the System Cables
7.
159
