6.
The remainder of the configuration settings will be performed via the Web UI (accessed via an
external workstation with a web browser such as Firefox

2.12.2.5 Setting up a Static IP Address via Ethernet Cable

This procedure will allow you to configure SecureSync using the Web UI directly via the Eth
ernet port, if for some reason you prefer not to (or cannot) use a DHCP network.
1.
2.
3.
4.
The remainder of the configuration settings will be performed via the Web UI (accessed via an
external workstation with a web browser such as Firefox
see "The Web UI HOME Screen" on page 17.
CHAPTER
2
SecureSync User Reference Guide Rev. 23
Note:
If your SecureSync is configured with an Ethernet option card, use
0, 1, 2, 3 for eth0 – eth3.
Remove the serial cable, connect SecureSync to the network, and access the Web UI,
using the newly configured IP address. (For assistance, see "Accessing the Web UI" on
the next page)
First, disable DHCP using the front panel keypad and information display:
a.
Press the
key.
ü
b.
Using the arrow key, select
(To select a menu item, highlight it using the arrow keys, then press the ü key.)
c.
Select the Ethernet interface for which DHCP is to be disabled, such as
d.
Select
from the next menu. The display will show
DHCP
Action=Disabled
(The State is the current DHCP setting and the Action is the action to take. You can
only change the Action setting.)
e.
Press the
key once to select the action, then again to apply it.
ü
The front panel will now display the default static IP address
Change the workstation IP address to be on the same network as SecureSync.
Connect workstation and SecureSync with an Ethernet cable.
You may use an Ethernet crossover cable, but you do not have to.
Note:
®
or Chrome
from the menu.
Netv4
.
®
or Chrome
2.12  Setting up an IP Address
®
).
.
eth0
and
State=Enabled
.
10.10.201.1/16
®
). For more information,
51
