Pin Assignments
Pin No.
1
2
3
4
5
6
7
8
9
10
Table 5-20:
HAVE QUICK Output: Viewing Signal State
To quickly view if a HAVE QUICK Output is enabled or disabled, go to the option card's
Status Summary panel. For instructions, see: "Viewing an Input/Output Signal State" on
page 331.
HAVE QUICK Output: Edit Window
To configure a HAVE QUICK Output , go to its Edit window. For instructions, see: "Configuring
Option Card Inputs/Outputs" on page 330.
The Web UI list entries for this card are: HAVE QUICK out, BNC and HAVE QUICK Out, RS-
485 .
The outputs are named: HQ Output [number] .
432
Function
HAVE QUICK Output 1 +
HAVE QUICK Output 1 -
GND
HAVE QUICK Output 2 +
HAVE QUICK Output 2 -
HAVE QUICK Output 3 +
HAVE QUICK Output 3 -
GND
HAVE QUICK Output 4 +
HAVE QUICK Output 4 -
1204-1B terminal block pin-out
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out
puts start at 1, because of the built-in outputs).
