1.7 Specifications
Spectracom recommends: LITTELFUSE 0213002.MXP
[Spectracom part number: F010R-0002-000 E FUSE,2A,SB,IEC SURGE,GLASS]
Number : 2 (two) per unit
SecureSync label on rear panel of unit:
" AC POWER/F 2A T 250V (2) "
1.7.2

GNSS Receiver

Compatible signals :
GPS L1 C/A Code transmissions at 1575.42 MHz
GLONASS L1 0F transmissions centered at 1602.0 MHz
QZSS L1-SAIF (1575.42 MHz)
BeiDou B1 (center frequency 1561.098 MHz)
Galileo-ready E1B/C (firmware upgrade required)
Satellites tracked : Up to 72 simultaneously
Update rate : up to 2Hz (concurrent)
Acquisition time : Typically < 27 seconds from cold start
Antenna requirements : Active antenna module, +5V, powered by SecureSync, 16 dB gain min
imum
Antenna connector : Type N, female
22
LEGEND:
F = Fuse
2A = Current Rating: 2 Ampères
T = Speed: Time Delay (Slow-Blow)
L = Breaking Capacity: Low (Glass)
250V = Voltage Rating
(2) = Fuses used: 2 (two)
Caution: Before testing fuses, remove AC power by disconnecting the AC power
cord.
Note: In the event that the unit does not power up with AC power, these fuses
should be tested.
